Ethernet Bluetooth AoA
AG3 Positioning Gateway
Experience pinpoint indoor positioning with the Lansitec AG3 Positioning Gateway, a high-precision locator designed to simplify large-scale tracking in warehouses, visitor facilities, and other challenging environments. By leveraging Bluetooth 5.1 and an advanced antenna array, the AG3 delivers sub-meter accuracy (0.1–1 m) and quickly synchronizes data through 4G/5G or Wi-Fi backhaul. The robust IP66-rated enclosure and flexible mounting options (ceiling or angled installation) make it suitable for both industrial and semi-outdoor scenarios, while PoE or DC (12–30 V) power supply ensures minimal cabling hassles. Whether you’re coordinating a sprawling distribution center or securing high-traffic public venues, the AG3 Positioning Gateway’s combination of remote configuration tools and on-board intelligence helps you manage assets and personnel in real time—with ease and confidence.
AG3 Positioning Gateway Features
What Makes it Unique
-
Precision Tracking (0.1–1 m) Bluetooth 5.1 combined with an optimized antenna array delivers near real-time, high-accuracy positioning.
-
Multi-Interface Backhaul Choose from 4G, 5G, or Wi-Fi (IEEE 802.11ac) for data transmission, ensuring consistent performance across varied network conditions.
-
IP66-Grade Enclosure Rated for operation from -20 °C to +60 °C, with ABS+PC housing that resists dust, water, and impact.
-
Power Flexibility Supports DC input (12–30 V/1 A) or PoE, reducing installation complexity and cost.
-
Intelligent On-Board System A 64 MHz Arm Cortex-M4 CPU, 512 KB Flash, and 128 KB RAM enable remote configuration, firmware updates, and robust local processing.
-
Wide Coverage Radius Covers up to twice its mounting height (max 15 m), optimizing device usage and lowering deployment expenses.
AG3 Positioning Gateway Use Cases
What it Could be Used for
Logistics Warehouse
Implement high-accuracy tracking to locate specific pallets or forklifts swiftly. By monitoring real-time positions, operators reduce lost inventory and boost operational efficiency.
Visitor Management
Ensure safety and seamless navigation within large venues (e.g., theme parks, nursing homes, prisons). The AG3 alerts staff if visitors stray outside permissible zones or if an emergency arises, enabling swift response.
Personnel Tracking
Protect employees or contractors working in hazardous zones by setting up geo-fences. Automatic alerts if someone enters a restricted area improve compliance with safety regulations and reduce the risk of accidents.
Vehicle Monitoring
Ideal for multi-level parking garages or distribution centers, capturing precise vehicle positions. Combine with 4G/5G backhaul for fleet scheduling and dispatch optimization in real time.
Resource Planning
Collect and analyze position data for tools, robots, and automated guided vehicles (AGVs). Improve route planning, prevent idle assets, and keep maintenance teams informed for proactive part replacements or servicing.
Technical Details
Product Specifications
Mechanics
Dimension
180.7*180.7*39.36mm
Weight
611±5g
Color
White
Material
ABS+PC
Installation Method
Ceiling mouting / Side mounting, angle ≤ 45°
Installation Height
Max 10m
Switch
PoE Powered, self-starting
Indicator Light
1 red and green status indicator + 1 ethernet port indicator
Environment & Electric
Power Supply
DC Power Supply (12-30V 1A)
Operating Temperature
-20°C ~ +60°C
Storage Temperature
-40°C ~ +85°C
IP Rating
IP66
Power Consumption
＜3W
Bluetooth Chip
CPU
64 MHz Arm Cortex-M4
Storage
512 KB Flash + 128 KB RAM
Protocol Standard
Bluetooth 5.1/4.2
Sensitivity
-96 dBm
Band
2.401 ~ 2.481 GHz
RF Specification
Supported TX Power
+8 ~ -20dBm configurable in 4 dBm step
Positioning Accuracy
0.1 ~ 1m
Coverage Range
Maximum coverage radius is double of the installation height, but not over 15m
Speed
10 / 100Mbps
Antenna
Array Antenna
Others
Internet Indicator
Support
Online Gateway Configuration and Update
Support
Online Beacon Configuration and Update
Support
Wifi
IEEE 802.11ac
FE
IEEE 802.3
Reset Button
1 Reset Button
Burn Interface
JTAG
Debug Interface
Serial Port
