Lansitec LoRaWAN Container Tracker is designed based on GNSS, Bluetooth and LoRaWAN technology for indoor and outdoor tracking. It has an ultra-long standby time and IP68 enclosure that makes it perfect for asset tracking.
It is suitable for the following use cases:
Product Specifications
Bluetooth
Bluetooth Protocol
5.0, iBeacon
Bluetooth TX Power
-20 to +4 dBm TX power, configurable in 4 dB steps
Bluetooth Sensitivity
-96dBm
LoRaWAN
LoRaWAN Protocol
1.0.2B, Class A
Activation Mode
OTAA or ABP
LoRa Band
US915, AU915, EU868, EU433, AS923, RU864, KR920, IN865, CN470
LoRa TX Power
0 to 20dBm
LoRa Sensitivity
-137dBm @SF12, BW125kHz, 868MHz/915MHz
LoRa Communication Distance
>1km in urban area
Encryption
AES128
GNSS
GNSS Band
GPS, BDS, GALILEO, GLONASS, QZSS, SBAS (WAAS, EGNOS, GAGAN, MSAS)
GNSS Position Accuracy
<2.5m CEP
Cold Start Duration
30s to 60s
Mechanics
Dimension
198*28*33mm
Ingress Protection
IP68
Operating Temperature
-45°C ~ +85°C
Storage Temperature
-60°C ~ +90°C
Operating Humidity
0% ~ 95% (non-condensing)
Housing Material
PC and ABS
Weight
133g
Power
Battery
Li/SOCl2 4000mAh x 2
GNSS (report interval＞10minutes)
Approx. 30,000 times
Bluetooth Positioning
Approx. 500,000 times
Standby Current
15μA
Max. Current
145mA
Function
Adjustable Position Report Interval
5s x n (1 to 65536)
Heartbeat Report Interval
30s x n (1 to 65536)
Switch
Magnetic Reed
Temperature Report
Optional, please advise Lansitec upon ordering
Temperature Sensor Range
-40°C~+85°C
Temperature Accuracy
Chamber temperature in the beacon, ±5
Temperature Resolution
0.25°C
Tamper Detection
Support
FOTA over Bluetooth
Support
Movement Duration
Support
Door Open/Close Sensing
Support
Vibration Shock Detection
Support
Asset Management with Bluetooth Tags
Support (report nearby Bluetooth tags)
Offline Cache Position (40 Positions)
Support
Magnetic Power Switch Enable/Disable
Support
3D Accelerometer
Support
NFC Tag
1KB
Reach out to us if you’re looking for a cost-effective tracking solution, a partner within your region or simply want to learn more about our technology.
