LoRaWAN Smart Badge Tracker

LoRaWAN Smart Badge Tracker

Lansitec badge tracker is designed based on GNSS, Bluetooth 5.0 and LoRa technology. It supports indoor and outdoor tracking. The badge is mainly used for personnel and asset management. Its built-in 3-axis accelerator could be used for determining the motion status of the terminal. Therefore, it can help save battery and enhance user experience.

It is suitable for the following use cases: visitor management, factory worker tracking, construction worker tracking, vehicle tracking, worker tracker etc.

Indoor Tracking: Bluetooth, 1~3m precision Outdoor tracking: GNSS, 2.5m precision Geo-fence

3-axis-accelerator, and illegal movement alert are supported

Once the LoRa environment is built, there will be no network surcharge

The positioning interval is adjustable, standby time can be extended to 5 months

PARAMETERS

Connectivity

Bluetooth Protocol

Bluetooth 5.0

LoRaWAN Protocol

LoRaWAN 1.0.2B

LoRaWAN Band

US915, AU915, EU868, EU433, AS923, RU864, KR920, IN865, CN470

LoRa Distance

>1km in urban area

LoRa Sensitivity

-139dBm @SF12, BW125kHz, 434MHz/470MHz
-137dBm @SF12, BW125kHz, 868MHz/915MHz

Bluetooth Distance

150m sight distance

Indoor Tracking

Bluetooth, 1~3m accuracy

Outdoor Tracking

GNSS, <2.5m CEP

Mechanics

Dimension

97*62*7mm

Operating Temperature

-10°C ~ +60°C

Storage Temperature

-40°C ~ +85°C

Weight

28g

Operating Current

20μA ~139mA

Function

3D Accelerometer

Supported

Encryption

AES128

Low Battery Alert

Supported

Vibration Intensity Adjustment

Supported

Buzzer

Supported

NFC

Supported

Operating Mode

GNSS coordinates acquisition frequency adjustable,LoRa communication frequency adjustable, Automatic BLE and GNSS tracking switching

Power

Battery

Li-ion rechargeable battery, 600mAh

Charging Method

Micro USB

Battery Life

Maximum 5 months

Certifications

Certification

CE, FCC, RCM
