Outdoor LoRaWAN Gateway
Lansitec Outdoor LoRaWAN Gateway is an ideal product for IoT commercial deployment. Its modularity and customization options allow for flexibility when deploying a solution. With its industrial-grade components, it achieves a high standard of reliability.
The gateway provides for a solid out of the box experience for quick deployment. Additionally, since its software and UI sits on top of OpenWRT it is perfect for the development of custom applications (via the open SDK). Thus the gateway is suited for any use case scenario, be it rapid deployment or customization with regards to UI and functionality.
- Support LTE Cat4 cellular mobile network
- Support WiFi and GNSS functions
- PoE (802.3 af) + Surge protection
- Equipped with IP67 protection grade shell, suitable for outdoor use
- Private or public LoRaWAN Network server is available
- Suitable for industrial operating temperature range
PARAMETERS
WiFi Feature
Frequency
2.400-2.4835GHz(802.11b/g/n)
RX Sensitivity
-95dBm (Min)
TX Power
20dBm (Max)
Operation Channels
2.4GHz: 1-13
LoRa Feature
Card
SX1301 Mini PCIe Card (connects maximum of two)
Channels
8 Channels (Optional: 16 channels)
RX Sensitivity
-139dBm (Min)
TX Power
27dBm (Max)
Frequency
EU433, CN470, EU868, US915 , AS923, AU915, KR920, IN865
Cellular Feature
Supports Quectel EG95-E / EG95-NA(IoT/M2M-optimized LTE Cat 4 Module)
EG95 -E for EMEA Region:
EG95 -NA for North America:
LTE FDD:
LTE FDD:
B1/B3/B7/B8/B20/B28A
B2/B4/B5/B12/B13
WCDMA: B1/B8
WCDMA: B2/B4/B5
GSM/EDGE: B3/B8
Mechanics
Power Supply
PoE(IEEE 802.3af/at-Compliant) - 42~57VDC; Power Jack - 12V DC
Power Consumption
12W (Typical)
ETH
RJ45 (10/100Mbps)
Antenna
5 N-Type Connectors
Ingress Protection
IP67
Enclosure Material
Aluminum
Weight
Approximately 111.11oz (3.15kg)
Dimension
220mm x 220mm x 104mm
Operating Temperature
-30°C to +55°C
Storage Temperature
-40°C to +85°C
Operating Humidity
0% to 95% (non-condensing)
Storage Humidity
0% to 95% (non-condensing)
Installation Method
Pole or Wall mounting
Computing
MT7628, DDR2RAM 128MB
Certifications
Certification
CE, FCC, RCM
