Lansitec NB-IoT and LTE-M GNSS container tracker supports indoor and outdoor tracking, asset management with worldwide network coverage. It has 5-year battery life (30 minutes report interval) and IP68 enclosure and is perfect for tracking container, pallets, and assets in a wide are.
Product Specifications
Connectivity
Protocol
MQTT, HTTP(S)
LoRaWAN
Optional
LTE-M
Band: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B85
Data Rate (Peak): 588 (DL), 1119 (UL)
NB-IoT
Band: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85
Data Rate (Peak): Cat NB2: 127 (DL) 158.5 (UL) Cat NB1: Max. 32 (DL) Max. 70 (UL)
Wifi
Band: Optional, 2.4GHz, positioning only
Data Rate (Peak): N/A
SIM Card
Band: Nano and eSIM
Data Rate (Peak): N/A
Bluetooth
Bluetooth Protocol
5.0, iBeacon, Eddystone, private
Bluetooth TX Power
-20 to +4 dBm TX power, configurable in 4 dB steps
Bluetooth Sensitivity
-96dBm
GNSS
GNSS Band
GPS, BDS, GALILEO, GLONASS, QZSS, SBAS (WAAS, EGNOS, GAGAN, MSAS)
GNSS Position Accuracy
<2.5m CEP
Cold Start Duration
30s to 60s
AGPS
Support
Mechanics
Dimension
198*28*33mm
Ingress Protection
IP68
Operating Temperature
-45°C~+85°C
Storage Temperature
-60°C~+90°C
Operating Humidity
0% ~ 95% (non-condensing)
Housing Material
PC and ABS
Weight
130g
Battery Life
GNSS (report interval >10minutes)
Approx. 11,000 times
Bluetooth Positioning
Approx. 24,000 times
Battery
Li/SOCl2 4000mAh x 2
Function
Adjustable Position Report Interval
5s x n (1 to 65536)
Heartbeat Report Interval
30s x n (1 to 65536)
Switch
Magnetic Reed
Removal Detection
Support
FOTA over Bluetooth
Support
Temperature Report
Optional, please advise Lansitec upon ordering
Temperature Sensor Range
-40°C~+85°C
Temperature Accuracy
Chamber temperature in the beacon, ±5
Temperature Resolution
0.25°C
Other
3D Accelerometer
Support
PCB Coating
Water proof coating
NFC Tag (optional)
1KB
Standby Current
25μA
Max. Current
200mA
