Bluetooth Beacon Tracker

B006 Badge
Bluetooth Beacon

The beacon constantly advertises iBeacon information according to settings. It has a built-in 600mAh rechargeable battery (non-rechargeable 440mAh version is also available) with adjustable advertising interval. The maximum standby time is approximately 1 year.

Badge Tracker

Product Specifications

Connectivity

Beacon Protocol

iBeacon

RF Power

4dBm to -20dBm in a 4dB step (Bluetooth 5.0)

Coverage Range

150m sight distance

Advertise Interval

100ms ~ 5s adjustable

Bluetooth Protocol

Bluetooth 5.0

Sensitivity

-97dBm

Supply Capacity

>300k/month

Mechanics

Material

ABS

Colour

White

Dimension

97*62*7mm

Operating Temperature

-10°C~+65°C

Storage Temperature

-20°C~+80°C

Operating Humidity

5% ~ 95% (non-condensing)

Function

Temperature Report

Optional, please advise Lansitec upon ordering

Temperature Sensor Range

-40°C~+85°C

Temperature Accuracy

Chamber temperature in the beacon, ±5

Temperature Resolution

0.25°C

Power

Battery Option 1

Li-ion rechargeable battery, 600mAh

Battery Option 2

440mAh (2 x CR2032) non-rechargeable battery

Battery Life

One year (TX Power 0dBm, 1s interval)

Certifications

Certifications

Exib II CT4
