Bluetooth Beacon

The beacon constantly advertises iBeacon messages according to settings. It has two built-in high-capacity button cells. The maximum battery life is approximately 5 years with a advertise interval @500ms.

The beacon is mainly used for indoor tracking and asset tracking. It can also be attached to assets and therefore used for asset tracking with the help of our Bluetooth gateways.

PARAMETERS

Beacon Protocol

iBeacon

RF Power

20 to +4 dBm TX power, configurable in 4 dB steps*

Sensitivity

-96dBm

Advertise Interval

100ms ~ 10s adjustable

Bluetooth Protocol

Bluetooth 5.0

Coverage Range

120m, sight distance

Supply Capacity

>300k/month

Frequency

2.4GHz

Battery Model

CR2477 (1000mAh) x2

Battery Capacity

2000mAh

Battery Life

5 Years (0dBm, 0.5s transmit interval)

Material

PC

Colour

White

Dimension

82*64*21mm (with the lug)

Weight

43g

Operating Temperature

-20°C~+70°C Optional: 1200mAh battery, -40°C~+125°C

Ingress Protection

IP68
