Solar Powered LoRaWAN Gateway

LoRaWAN
Solar Bluetooth Gateway

Lansitec Solar Bluetooth Gateway is designed based on LoRaWAN and Bluetooth 5.0 technology. It receives nearby Bluetooth beacon messages, and then transmit to a LoRaWAN gateways through
LoRaWAN after restructure the data. It is powered with robust solar film and a 5300mAh rechargeable battery.

Solar Bluetooth Gateway

Product Specifications

Connectivity

Bluetooth Protocol

Bluetooth 5.0

LoRaWAN Protocol

LoRaWAN 1.0.2B

LoRaWAN Band

US915, AU915, EU868, EU433, AS923, RU864, KR920, IN865, CN470

LoRa Maximum RF Power

20dBm

High TX Power Option

Max. 30dBm and -150dBm receiving sensitivity

LoRa Sensitivity

-139dBm @SF12, BW125kHz, 434MHz/470MHz -137dBm @SF12, BW125kHz, 868MHz/915MHz

Access Quantity

>500 in one LoRaWAN gateway

Data Rate(bps)

300~30K

Mechanics

Dimension

160*160*55mm

Operating Temperature

-40°C ~ +70°C

Charging Temperature

-20°C ~ +60°C

Storage Temperature

-45°C ~ +85°C

Operating Humidity

0% ~ 95% (non-condensing)

Weight

460g

Ingress Protection

IP66

Function

Positioning Precision

3m

Encryption

AES128, X509

Power

Battery

Li-ion rechargeable battery 5300mAh

Solar Panel

3W

Battery Life

Adjustable Position Report Interval: 5s x n (1 to 65536) Heartbeat Report Interval: 30s x n (1 to 65536) Switch: Mechanical Customized data filter and data report: Support FOTA over Bluetooth: Support
Max. Beacons Supported: 105 **, maximum of 15 beacon messages at one single LoRa communication @SF9

Certification

Certification

CE, FCC, RCM
