Lansitec

LTE Cat-1
Asset Management Tracker

The Cat-1 Asset Management Tracker unites multi-GNSS, BLE 5.0 and LTE Cat-1 for always-connected indoor & outdoor asset intelligence. Its twin 4 000 mAh Li-SOCl2 cells (8 000 mAh total) power up to 3+ years of adaptive reporting inside an IP68, palm-sized enclosure. Motion sensors, tamper switch and door-open detection transform raw position pings into actionable utilisation data—ideal for containers, transit cases and unattended machinery.

UWB Asset Management Tracker

Asset Management Tracker (Cat-1) Features

What Makes it Unique

  • Global Cat-1 Coverage 25 + FDD bands with MQTT / HTTP(S) / TCP / UDP uplinks.
  • Dual-Mode Positioning < 2.5 m CEP by GNSS outdoors; 3 m BLE RSSI indoors.
  • Edge Smart Rules Geo-fence, motion duration, shock, door and tamper alerts on board.
  • Ultra-Long Autonomy 15 µA sleep current yields 30 k GNSS or 500 k BLE reports.
  • Offline Cache & Burst Stores 40 locations when out of coverage, uploads on reconnect.
  • Asset BLE Tag Sync Inventories nearby beacons to know what is inside each case.
  • Wide Temp Range −45 °C … +85 °C operation, waterproof-coated PCB.
  • FOTA & NFC Provisioning Firmware upgrades and tap-to-pair setup without unsealing.

Asset Management Tracker (Cat-1) Use Cases

What it Could be Used for

Factory Machine Status Monitoring LoRaWAN Container Tracker

Machine-Status Monitor

Correlate vibration hours and shock spikes to schedule maintenance and prevent downtime.

Cold Chain Logistic Temperature Monitoring

Cold-Chain Compliance

Pair with BLE temperature probes inside vaccine coolers; Cat-1 pushes threshold breaches instantly.

Visitor Experience at Tourist Attractions with B004 Bluetooth Beacon

Museum & Exhibit Security

Shock-, motion- and door-sensing safeguard priceless artifacts during transit and storage.

Enhancing Container Tracking Efficiency with Lansitec LoRaWAN

Container Tracking

Real-time GNSS & door-open alerts secure sea-rail containers through ports, depots and yards.

Relative Articles

More Cases

Lansitec Container Tracker Bringing LoRaWAN and NB-IoT in Modern Logistics
May 20, 2024

Lansitec Container Tracker Bringing LoRaWAN and NB-IoT in Modern Logistics

Lansitec Unveils Advanced Container Trackers for Superior Asset Management
May 20, 2024

Lansitec Unveils Advanced Container Trackers for Superior Asset Management

Improved Logistics Business with Cat-1 Trackers and Bluetooth Beacons
March 26, 2025

Improved Logistics Business with Cat-1 Trackers and Bluetooth Beacons

Technical Details

Product Specifications

Mechanics

Dimension

78*79*35mm with the mounting lugs; 78*66*35mm without the mounting lugs

Weight

133g

Ingress Protection

IP68

Housing Material

PC and ABS

PCB Coating

Water proof coating

Operating Temperature

-45°C ~ +85°C

Storage Temperature

-60°C ~ +90°C

Operating Humidity

0% ~ 95% (non-condensing)

Power

Battery

Li/SOCl2 4000mAh x 2

GNSS (report interval >10minutes)

Approx. 30,000 times

Bluetooth positioning

Approx. 500,000 times

Standby Current

15μA

Max. Current

145mA

Cat-1

Regions

North America

Europe / Africa

China / India

Latin America

FFD

B2/B4/B5/B12/B13/ B66

B1/B3/B5/B7/B8/B20

B1/B3/B5/B8

B2/B3/B4/B5/B7/B8/B28/ B66

TTD

N/A

N/A

B34/B38/B39/B40/ B41

N/A

SIM Card

Nano or eSIM

Protocol

MQTT, HTTP(S), TCP, UDP

Bluetooth

Bluetooth Protocol

5.0, iBeacon, Eddystone, private

Bluetooth TX Power

-20 to +4 dBm TX power, configurable in 4 dBm steps

Bluetooth Sensitivity

-96dBm

GNSS

GNSS

BDS/GPS/GLONASS

GNSS Position Accuracy

<2.5m CEP

Cold Start Duration

30s to 60s

AGPS

Support

Functions

Adjustable Position Report Interval

5s x n (1 to 65536)

Heartbeat Report Interval

30s x n (1 to 65536)

GNSS Position Report Interval

5s xn (1 to 65536)

FOTA over Bluetooth

Support

Temperature Report

Optional, please advise Lansitec upon ordering

Temperature Sensor Range

-40°C~+85°C

Temperature Accuracy

Chamber temperature in the beacon, ±5°C

Temperature Resolution

0.25°C

Cellular-based Positioning

Support

Configurable Bluetooth data filter and payload report

Filter any data bytes in a Bluetooth payload and report any via Cat-1

Bluetooth data compression

Support
