AG1 Positioning Gateway

The gateway uses BLE AoA (Angle of Arrival) precision positioning technology, with highprecision
positioning antenna array, high-precision adaptive algorithm, and real-time positioning up to 0.1M.

This product uses standard Ethernet data communication, 802.3af PoE 48V power supply mode, and supports PoE cascading power supply mode, reducing wiring length, saving switch ports, and reducing costs.

Supports both Android phone and IOS phone as a tag
Single locator supports high-precision two-dimensional positioning
The only high-precision positioning solution for mobiles, the positioning quality is basically the same as beacon
Suitable for various of hardhats and helmets, Magnetic charging port.

PARAMETER

Communication Protocol

BLE

Frequency Band

2.401~2.482GHz

Antenna Type

PCB Antenna

Advertise Power

-30~+4dBm,default 0dBm

Advertise Frequency

100ms~10s,default 500ms

Positioning Coverage Radius

The same as the height(Open environment)

Positioning Capacity

300beacons @ 1s advertisement interval

Data Communication Mode

Ethernet IEEE802.3 af

Ethernet Speed

10/100Mbps

Network Indicator LED

Support

Positioning Accuracy

0.3~1m

Power Consumption

<2w

Operating Temperature

-20℃~80℃

Storage temperature

-40℃~80℃

Humidity

0%~90%

Power Supply

PoE 48V IEEE 802.3af/DC12V~30V 1A

Material

ABS+PC

Colour

White

Dimensions

180×180×39mm

Weight

570g
